An open web steel joist bears on a steel column topped with a steel cap plate, adjacent to a concrete tilt-up wall panel. A continuous deck bearing angle is embedded in the concrete panel to support the metal roof deck. The joist bearing end is secured with two three-quarter inch diameter erection bolts. A stabilizer plate measuring six inches by three-quarters of an inch by zero feet six inches with a thirteen-sixteenths inch diameter hole connects to the joist, with a note specifying not to weld bottom chords to the stabilizer plate unless noted otherwise. Three-sixteenths inch fillet welds are specified throughout the connection assembly.
CONC TILT-UP PANEL, SEE SCHEDS AND ELS REVEAL OR RECESS (WHERE OCCURS) SEE ARCH PLANS FOR MORE INFO (3/4" MAX) TYP 1" STL CAP PL, SEE COL SCHED FOR SIZE L3x3x1/4 x CONT DECK BEARING ANGLE TYP DECK BEARING EMBED SEE L3x3x1/4 x 0'-8" LONG AT JST STL COL NOTE: DO NOT WELD BOTT CHORDS TO STABILIZER PL, TYP UNO STL JST STABILIZER PL 6"x3/4"x0'-6" W/ 13/16"Ø HOLE, TYP AT JSTS TYP 3/16 TYP 3/16 3/16 TYP 3/16 MTL ROOF DECK 5" DEEP JST BRG END W/ (2) 3/4"Ø ERECTION BOLTS TYP 3/16
