A steel beam frames into a column with a complete-joint-penetration groove weld at the flange to a continuous plate. A top continuous plate is installed per detail 8/S5-01. A 3/4 inch thick plate is provided where no continuity plate is required. A W8x10 closure angle is attached at the slab edge with a two-inch projection. Fillet welds of 1/4 inch and 5/16 inch sizes secure the framing connections.
CLOSURE ANGLE W8x10 PL 3/4" THK WHERE NO CONTINUITY PL REQUIRED TOP CONT PL PER 8/S5-01 COL 1C - SECTION e > 8" 2" 1/4 5/16 CJP FLANGE TO CONT PL "A" 3/16
