A steel beam supports a steel deck spanning overhead with an adjacent structural angle measuring 3x3x3/16 connected to the top flange. A five-inch by quarter-inch by five-inch weld plate is positioned typically at each end of the member. A one-and-a-half-inch clearance dimension is indicated near the structural interface.
STEEL DECK SF531 D3 L3x3x3/16 TO TOP FLANGE OF ADJACENT BEAM 5"x1/4"x5" WELD PLATE TYP EACH END STEEL BEAM 1 1/2"
