Structural · S-73Y97

Beam To Perimeter Beam

Materials

Steel

Elements

Beams Connections / Plates

Connections

Shear Tab / Single Plate Bolted Connection Expansion / Slip Connection

About this detail

The framing beam connects to the perimeter beam using a full-height shear tab sized per schedule, utilizing no slotted holes to steel. For W8, W10, W12, and W14 beams, a one-half-inch rectangular plate option is included at the bottom, along with an additional unslotted bolt when the distance is four inches or greater. For W16 and deeper beams, the full-height shear tab connection is detailed with a maximum four-inch dimension without the bottom plate requirement. AISC manual "K" distance clearances apply to the perimeter beam web and flange junctions.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
