Number four dowels spaced at twenty-four inches on center tie the concrete panel to the slab unless noted otherwise. Slab reinforcement terminates at the designated line shown on the drawing.
TERMINATE SLAB REINF. TYP. @ THIS LINE #4 DOWELS @ 24" O.C. FROM PANEL TO SLAB TYP. @ THIS LINE U.N.O. F2 C1
