The truss girder connects to a precast concrete wall panel utilizing three three-eighths-inch gusset plates welded with a five-sixteenths-inch fillet weld. The precast concrete wall panel features reinforcing steel detailed per the panel elevation. Dimensions space the gusset plates symmetrically across the centerline of the truss girder.
2" 2" PLAN VIEW (3) 3/8" GUSSET PL 4" C OF TRUSS GIRDER L 4" 8" 8" 17 - 5/16 PRECAST CONCRETE WALL PANEL REINFORCEMENT SEE PANEL ELEVATION 4"
