Two concrete panels meet at a mitered corner with a continuous internal joint gap. A steel angle ledger measuring 2-1/2 inches by 2-1/2 inches by 1/2 inch and 3 inches long is embedded or anchored at the interior corner. The steel ledger is secured with a one-quarter inch fillet weld indicated on the drawing. Embedded anchor studs tie the panels back structurally. The assembly provides structural alignment and transfer at exterior panel corners.
