A hollow structural section is enclosed within a two-by-four wood stud framing curb topped with half-inch plywood for roofing support. The curb assembly sits on existing plywood over an existing four-by four wood member, secured with two sixteen-penny nails spaced at twenty-four inches on center maximum. A note indicates that the roofing contractor may submit an alternate detail.
