Structural · S-6VEQT

Typical Gusset At Roof Framing

Materials

Steel

Elements

Columns Beams Roofs Connections / Plates

Connections

Braced Frame Connection Gusset Plate

About this detail

A gusset plate connection at a roof framing braced frame ties a wide-flange beam and a buckling-restrained brace into a wide-flange column. The gusset plate features a thickness and width matching the beam flange, with half-inch stiffener plates welded to the column and gusset using five-sixteenth-inch fillet welds on three sides, omitting where H-plates conflict. Gusset stiffeners are placed on each side and aligned with the beam flange, maintaining a two-inch clearance and coordinating with the buckling-restrained braced frame supplier. The wide-flange beam connects per the special connection schedule, while the column and gusset incorporate designated working points and reference dimensions per schedule.
