Structural · S-6TXPT

Pe3 Elevator Pit Section

Materials

Concrete Reinforced Concrete

Elements

Arches Beams Floors / Slabs Foundations / Footings Reinforcing Site / Paving Waterproofing / Flashing

Connections

Rebar Splice / Development

About this detail

This structural detail shows an elevator pit section bearing on piles with a reinforced concrete slab and grade beam assembly. The foundation pile cap incorporates fifteen-millimeter reinforcing bars spaced at two hundred millimeters each way and each face, with thirty-millimeter top and bottom bars spanning the pit floor. Concrete construction joints require roughened and cleaned surfaces to achieve a plus-or-minus five-millimeter roughness amplitude. Vertical and horizontal dampproofing and horizontal vapor barriers are installed per architectural specifications. A typical waterstop is embedded at the wall-slab joint, and a concrete curb extends at the top of the pit wall.
