A concrete ramp slab on grade connects to a tilt-up wall panel. The ramp slab features thickness and reinforcement sized per plan, maintaining a typical one-inch clearance. Dowel bars measuring two feet six inches long tie the slab into the wall panel, with their size and spacing matching the slab on grade reinforcement. A Lenton form saver mechanical coupler embeds in the tilt-up wall panel to receive reinforcing dowels projecting from the slab. The wall panel reinforcement size and spacing match the slab on grade reinforcement with a two-inch clear cover.
