A structural steel beam frames into a supporting column flange using a full-depth shear tab connection. The single plate has a width matching the beam flange thickness and is fastened with bolts sized per the primary connection schedule. Additional elevation dimensions and connection requirements reference standard detail Type C1.
BOLTS PER "TYP STEEL CONN, TYPE C1" FULL DEPTH SHEAR TAB, WIDTH TO MATCH BM FLG THICK PER "TYP STEEL CONN, TYPE C1" PER C1 CONN PER PLAN TOS EL NOTES: 1. SEE "TYPICAL STEEL CONNECTION, TYPE C1" FOR ADDITIONAL ELEVATION 1/2" 2"
