Gravity and lateral wind and seismic load connections for cold-formed metal framing and curtainwalls occur at a composite concrete slab and wide-flange steel beam edge. The assembly accommodates a curtainwall system anchored below the horizontal mullion, supported by cold-formed metal framing kickers and framing members. When louvers are present below the soffit, cold-formed metal framing studs connect directly to a hollow structural section girt with gravity and lateral connections. The wide-flange beam and composite slab levels are sized per plan, and composite slab reinforcing is omitted for clarity.
SEE PLAN CURTAINWALL SEE ARCH GRAVITY & LATERAL CONN BY CURTAINWALL SUPPLIER BELOW HORIZONTAL MULLION GRAVITY & LATERAL CONN BY CFMF SUPPLIER WF BEAM SEE PLAN METAL PANEL W/ 8" CFMF BACKUP SEE ARCH CURTAINWALL OR LOUVERS SEE ARCH CFMF KICKERS AS REQD BY CFMF SUPPLIER WHEN CURTAINWALL IS PRESENT BELOW SOFFIT GRAVITY & LATERAL CONN TO UNDERSIDE OF COMPOSITE SLAB BY CFMF SUPPLIER HSS GIRT WHEN LOUVER IS PRESENT BELOW SOFFIT CFMF STUDS TO CONNECT DIRECTLY TO HSS GIRT W/ GRAVITY & LATERAL CONNECTIONS BY THE CFMF SUPPLIER COMPOSITE SLAB SEE PLAN NOTE: COMPOSITE SLAB REINFORCING NOT SHOWN FOR CLARITY NOTE: SEE 10/S-553 FOR INFORMATION NOT NOTED T/SLAB SEE PLAN T/STEEL SEE PLAN CFMF SHALL BE DESIGNED TO SUPPORT LATERAL WIND AND SEISMIC LOADS FROM CURTAINWALL
