A metal deck spans perpendicular across a wide-flange steel beam with a three-foot span and a maximum three-foot-three-inch overhang. A bent quarter-inch ASTM A36 steel plate forms the edge, secured with three-sixteenths fillet welds at twelve inches on center at each low flute of the deck. A minimum nineteen-gauge deck is used for large deck overhangs. Number four reinforcing bars are placed at twelve inches on center centered on the low flute.
DECK SPANNING PERPENDICULAR TO BEAM 3'-0" MAX 3'-3" 2" 2" PER DECK SUPPLIER OVERHANG DESIGN MAX 9" CW EMBED 6" MIN & 7.5" MAX CLR FOR BENT PL1/4 (A36) 2-12 3/16 AT EACH LOW FLUTE (1/2) #4 @ 12", CTR ON LOW FLUTE MIN 19GA DECK USED FOR LARGE DECK OVER HANGS
