Typical lap splice locations and set out dimensions for top and bottom reinforcing in concrete slabs spanning across typical columns. The top reinforcing lap splices are located at a distance of 0.3 times the span length from the supports, while bottom reinforcing laps occur over the intermediate column supports within a designated lap splice zone. Adjacent lap splices are staggered to prevent reinforcing congestion, and reinforcement is shown in a single direction for clarity with sizing sized per plan. Grid lines establish the primary span dimensions L1 and L2.
G.L. G.L. G.L. LAP L1 L2 0.3L1 0.3L2 LAP SPLICE ZONE COLUMN, TYP. BOTTOM SLAB REINF. SEE PLAN NOTES : 1. REINF. IN 1 DIRECTION (LAYER) SHOWN FOR CLARITY. 2. STAGGER OFFSET ADJACENT LAP SPLICES. 3. SEE FOR LAP SPLICE SCHEDULE REINF. G.L. G.L. G.L. L1 L2 TOP SLAB REINF. SEE PLAN L1/2 L2/2 ZONE = .3L1 LAP SPLICE ZONE = .3L2 LAP SPLICE BOTTOM REINFORCING TOP REINFORCING COLUMN, TYP. S5.400 1 TYP. SLAB LAP SPLICE SET OUT
