A masonry foundation wall bears on a continuous concrete footing with stepped profiles. Vertical reinforcing dowels match the vertical reinforcement and extend into the footing. Horizontal reinforcing bars run continuously through the masonry course. Z-bars match the continuous footing reinforcement and tie into the concrete footing. Transverse reinforcement is provided in the vertical footing to match the footing transverse reinforcement.
DOWELS TO MATCH VERT REINF 'Z' BARS TO MATCH CONT FTG REINF MAS FND WALL PROVIDE TRANSVERSE REINF IN VERT FTG TO MATCH FTG TRANSVERSE REINF 1.5 H MIN W 4'-0" MAX H CONC FTG TYP HORIZ REINF TYP HORIZ REINF
