An HSS4x4x1/4 hollow structural section is positioned at beam spacing over a metal deck with foam insulation. A one-quarter-inch bent plate connects to the HSS member. Typical plate-to-HSS connections are indicated throughout the assembly.
E HSS4x4x1/4 AT BM SPACING HSS4x4x1/4 INSULATION FOAM SAD 1/4" BENT PL TYP PL TO HSS 2-4
