A continuous 600T150-54 track fastens to cold-formed metal studs using two number ten screws at each stud, unless noted otherwise. A continuous sixteen gauge extension plate secures with two number ten screws at sixteen inches on center, positioned a maximum of two inches from the stud below. This plate may be omitted if the dimension 'X' is within the limits of the glazing manufacturer. The glazing system references architectural drawings.
'X' REF. ARCH (3" MAX.) AT SIM. 1/16 1/16 GLAZING SYSTEM, REF. ARCH. COLD-FORMED METAL STUDS, REF. ELEVATIONS CONT. 16 GA. EXTENSION PLATE W/ (2) #10 SCREWS @ 16" o.c. PLACE SCREWS 2" MAX. FROM STUD BELOW. (ACCEPTABLE TO OMIT PLATE IF 'X' IS WITHIN LIMITS OF GLAZING MANUF.) CONT. 600T150-54 TRACK W/ (2) #10 SCREWS AT EACH STUD, TYP. U.O.N. " Ø ASTM F1554 GRADE 36
