S-6M3GZ — Typical Steel Beam Connection to Steel Column

Structural · S-6M3GZ

Typical Steel Beam Connection to Steel Column

Materials

Elements

Columns Beams Decks Connections / Plates

About this detail

Steel beams frame into a vertical steel column utilizing bolted shear tabs on both webs. A steel cap plate finishes the top of the column flange between the supporting steel beams. Corrugated steel deck bears across the top of the structural steel framing.

JK1RSB09 STEEL CAP PLATE STEEL COLUMN STEEL DECK TYP STEEL BEAM STEEL BEAM STEEL BEAM

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
