A buckling-restrained brace connects to a gusset plate welded to a steel column and beam assembly. The gusset plate is attached with complete joint penetration welds on three sides, and three-quarter-inch thick stiffener plates are positioned in four places. A backing plate measuring three-eighths by four inches by one foot four inches includes two three-quarter-inch diameter erection bolts. The concrete over metal deck is sized per plan, and the brace and its bolted connection are provided by the buckling-restrained brace manufacturer.
NOTES: 1. 2. 3. (3) SIDES GRID CJP T&B CONC OVER METAL DECK PER PLAN BRACE PER BRB MFR W/ BOLTED CONN GUSSET PLATE PER BRB MFR CJP T&B CL COL CL WP= CL BEAM STIFF PL3/4, TYP (4) PLACES COL PER EL BACKING PL3/8x4x1'-4" W/ (2) 3/4"Ø ERECTION BOLTS T/STL PER PLAN BEAM PER EL WP TYP BRACE PER BRB MFR W/ BOLTED CONN @ SIM GUSSET PLATE PER BRB MFR @ SIM CL BRB S3.21 17 S3.21 12
