An interior reinforced concrete column supports a post-tensioned slab featuring banded tendons and uniform tendons with mild reinforcing bars placed within a designated zone at equal spacing not exceeding twelve inches on center. Top reinforcing bars center over the column or wall, while bottom reinforcing bars span the assembly. A drop panel occurs at the column location where required, maintaining specified clearances for post-tensioning tendons and rebar.
BAY BOT BARS TOP BARS - CENTERED OVER COLUMN/WALL UNIFORM TENDONS (SEE NOTE 2) BANDED TENDONS (SEE NOTE 2) SEE PLAN CG (SEE NOTE 1) 3/4" CLR PT & REBAR 1" CLR MIN AT EXT (SEE NOTE 1) 3/4" CLR DROP PANEL - WHERE OCCURS 1.5H WIDTH COL/WALL 1.5H D SLAB THK T H AT EQUAL SPACING (MAX 12" OC, SEE NOTE 3) MILD REINF TO BE PLACED WITHIN THIS ZONE EA WAY SHEAR REINF WHERE OCCURS - SEE PLAN INTERIOR
