Steel beams connect to a hollow structural section steel column and to adjacent steel beams using bolted clip angles. The framing details show typical edge distances, bolt spacings, and weld configurations on three sides of the connection angles. Clearance dimensions maintain proper alignment between the structural members.
TYP. EA ANGLE 2 STEEL BEAM 3 SIDES BEAM TO BEAM CLIP ANGLE CONNECTION CLIP ANGLES STEEL BEAM 1 CLIP ANGLES BEAM TO TUBE COLUMN CLIP ANGLE CONNECTION 3 SIDES 3" 3" 1 1/2" MIN 1 1/2" 2" TYP. STEEL BEAM CLIP ANGLES 3 1/2" STEEL COLUMN STEEL BEAM 1 CLIP ANGLES 2 TYP. EA ANGLE
