A concrete slab depression is formed over a metal deck supported by a steel beam where it occurs. A continuous 16-gauge closure plate spans the deck flutes beneath the sloped depression transition. Reinforcement includes continuous number 4 bars and number 4 bars spaced at 12 inches on center within the slab.
#4 CONT #4@12" STEEL BEAM WHERE OCCURS WT OR ANGLE WHERE OCCURS 16GA CLOSURE PL CONTINUOUS 24" 24" PER PLAN 3D OR 9" MIN PER PLAN D (9" MAX) MIN 3" EQ EQ
