A structural steel column bears on a Grade 50 two-and-a-half-inch base plate secured by twelve two-inch diameter ASTM F1554 Grade 105 anchor bolts equipped with three-quarter by four by four-inch plate washers and double nuts. The column and baseplate assembly sits within a concrete slab pocket sized per elevation. A minimum thread projection of one-half inch must be maintained above the top of each nut. Slab control joints are referenced to a separate detail.
NOTES: 1. PROVIDE MINIMUM THREAD PROJECTION OF 1/2" ABOVE TOP OF EACH NUT. 2. REFERENCE DETAIL 7/S3.23 FOR SLAB CONTROL JOINT. GR50 BASE PL2 1/2 x AS SHOWN W/ (12) 2"Ø F1554 GR105 AB'S W/ PL3/4x4x0'-4" WASHERS & DBL NUTS 1/2 1/2 1/2 1/2 TYP STL COL PER EL SLAB POCKET AS SHOWN 4" 8" 11 1/2" 11 1/2" 8" 8" 6" TYP 4" 4'-9" 2'-0" COL C L 6" 6" 6"
