A single-story X-brace connection centers on a work point with intersecting brace centerlines. A 1/4-inch gusset plate connects the structural braces using 3/4-inch erection bolts. Fillet welds of 1/4-inch size are specified typically along the gusset plate connections. Dimensions locate the brace alignments and edge clearances across the intersection.
BRACE PER ELEVATION TYP TYP 2" 6" TYP 3" 3" 4" 4" 3 S331 3 S331 1/4" GUSSET PL CL BRACE 1/4 1/4 TYP Ø3/4" ERECTION BOLT TYP 1/4 1/4 WP
