Concrete beam construction joint detailing the transition between consecutive pours with a full-width keyway centered in the section. All beam reinforcing bars extend continuously through the joint. Two sets of beam stirrups are spaced at six inches on each side of the construction joint. The slab thickness is indicated as twelve inches typical.
EQ EQ EQ 6" KEY, FULL WIDTH OF BM (2) SETS OF BM STIRRUPS AT 6" EXTEND ALL BM BARS THRU JT FIRST POUR BEAM CONSTRUCTION JOINT 1 1/2" PLAN OF BEAMS RIGHT END OF BM LEFT END OF BM LEFT END OF BM B6 B5 BM MARK SEE "CONC BM SCHED" SLAB THK 12 TYPICAL CONCRETE BEAM
