A metal deck bears across a W10 steel beam with a channel framing element positioned below, maintaining a minimum two-inch and maximum six-inch overhang. Two number twelve self-drilling screw fasteners are provided in each deck rib in lieu of welds. A minimum of three deck flutes are maintained on each side of the opening. The channel framing is not required when located within one foot six inches of an adjacent beam.
DETAIL A TYP EA DECK RIB 1/2 IN LIEU OF WELDS, PROVIDE (2) #12 SELF-DRILLING SCREW FASTENERS EA DECK RIB C4 BELOW, NOTE 4 MIN (3) DECK 18" FLUTES, ES 13" C4 NOT REQD WHEN WITHIN 1'-6" OF ADJ BM CL BM SECTION W10 C6 TYP DECK ATTACHMENT 2" MIN, 6" MAX OVERHANG TYP AT C6, W10 STL BM 2"
