This structural steel fabrication detail specifies the geometric requirements for beam flange copes and weld access holes. The cutout incorporates a three-eighths-inch minimum radius and specified dimensions relative to the flange thickness denoted as tbf. A bevel is provided as required by AWS D1.1 for the selected groove weld procedure. Specifications govern the fabrication details including cutting methods and smoothness requirements.
3tbf (±1/2") 3tbf (±1/2") tbf LARGER OF tbf OR 1/2". (PLUS 1/2 tbf, OR MINUS 1/4 tbf) 3/4 tbf TO tbf, 3/4" MINIMUM (±1/4") 3/8" RADIUS MINIMUM BEVEL AS REQUIRED BY AWS D1.1 FOR SELECTED GROOVE WELD PROCEDURE. SEE SPECIFICATION FOR FABRICATION DETAIL INCLUDING CUTTING METHODS AND SMOOTHNESS REQUIREMENTS. 3/8" RADIUS MINIMUM SEE SPECIFICATION FOR FABRICATION TOP FLANGE
