Two-sided beam-to-beam shear tab connections frame into a supporting steel girder with conditions for both greater than and less than one inch of beam depth difference. A shear plate is welded to the supporting girder and bolted to the web of each incoming beam with bolts sized and spaced per AISC specifications. When beam depth differences exceed one inch, a WT shape matching the flange width is welded to the underside of the lower beam with a quarter-inch fillet weld and extended two feet. Weld backup plates are omitted from the graphical representation for clarity.
BEAM TO BEAM CONNECTION (TWO SIDED CONNECTION) F BEAM DEPTH DIFFERENCE > 1" BEAM DEPTH DIFFERENCE < 1" NOTE: WELD BACKUP PLATES NOT SHOWN FOR CLARITY TO STEEL NO & SIZE OF BOLTS (SEE NOTE 3) FOR BOLT SPACING AND EDGE DISTANCE SEE AISC SPECIFICATIONS, TYP SHEAR TAB (SEE NOTE 3) GIRDER (SEE PLAN) WT TO MATCH FLANGE WIDTH OF BEAM SHOWN ON PLAN THUS: 2'-0" 1/4 WT TO BEAM SEE NOTE 3 1" MAX . CP T&B FLANGES, TYP SEE NOTE 3 TYP M
