A knife plate connection at an interior hollow structural section or pipe column. A continuous knife plate passes through the centerlines of the column and girder line, with plate thicknesses sized per Schedule A. Shear plate information follows the typical shear plate connection details, maintaining typical edge clearances.
BEAM TO HSS OR PIPE COLUMN SHEAR PLATE INFORMATION PER TYPICAL SHEAR PLATE CONNECTION. CL COL & BEAM USE KNIFE PL ALONG GIRDER LINE TYPICAL SECTION AT INTERIOR COLUMN SCHED "A" (NOTE 7) CL COL & GIRDER "t" PER SCHED "A" TYP t+1/16" t+1/16" B
