A concrete wall rests on a continuous concrete footing set upon firm bearing material. Two fifteen metric bottom reinforcing bars run continuously within the footing assembly. Compacted backfill fills the stepped excavation zone adjacent to the foundation wall. Maximum horizontal step dimensions and required bearing lengths are explicitly dimensioned.
(2' - 0") 600 (6' - 0" MAX.) 1800 MAX. (2' - 0") 600 FIRM BEARING 2-15M BOT. CONCRETE WALL ONLY FIRM BEARING COMPACTED BACKFILL OPTION 3
