S-64T95 — Base Bearing Plate On Steel Beam

Structural · S-64T95

Base Bearing Plate On Steel Beam

Units: metric
Discipline: Structural

Materials

Elements

Beams Columns Connections / Plates

Connections

Base Plate / Anchorage Beam-to-Column HSS Connection Welded Connection

Text on the drawing

A A EXTEND SHEAR PL FOR INTERSECTING BEAM TO TOP FLANGE EA SIDE, WHERE NO INTERSECTING BEAM OCCURS, PROVIDE HSS COLUMN 5/16
