Footing and grade beam concrete reinforcement details show standard hooks and lap splices located at corners, intersections, and ends. Continuous longitudinal rebar runs through the members with specified lap splice lengths designated as 'Lts'. Standard 90-degree hooks anchor the ends of the reinforcing bars at corners and terminations. Intersecting grade beams maintain continuous bar development through the junction with standard hooks turning into the adjoining member.
STANDARD HOOK FOOTING / GRADE BEAM REBAR, TYP 'Lts' LAP SPLICE STANDARD HOOK AT END OF GRADE BEAM/ FOOTING PLAN 'Lts' LAP SPLICE STANDARD HOOK
