An armor-edge joint assembly is cast into a concrete slab according to manufacturer requirements. Joint reinforcement is installed per detail A1/S-501.
ARMOR-EDGE JOINT ASSEMBLY PER MFG. REQUIREMENTS JOINT REINF. PER DETAIL A1/S-501 CONC. SLAB SEE PLAN
