This structural connection features a vertical steel beam intersecting with two diagonal steel angles framing into a horizontal steel member at a common work point. The diagonal steel angles are welded to the supporting steel member with typical quarter-inch fillet welds. A three-inch minimum clearance or dimension is maintained at the angle and beam intersection typical. All structural steel elements are detailed for standard framing alignment.
