Dual steel beams frame into a hollow structural section column using bolted shear tabs at the top of steel level. The structural connection aligns with the centerline of the steel beams and column, maintaining specific edge clearances and a standard fastener gage. Specific connection details are cross-referenced to another drawing sheet.
GL ELEVATION A-A 1/2" TYP. 1" TYP. HSS COLUMN PER PLAN STEEL BEAM PER PLAN, TYP. T.O.S. CONN. PER 4 S0.21 OF STEEL BEAM and COLUMN GAGE
