A steel column connects to a steel base plate resting on a 1-1/2 inch non-shrink grout bed above a concrete footing. The base plate is anchored within a concrete blockout surrounded by a concrete slab on grade. A reinforced concrete wrap surrounds the lower portion of the steel column to match the finished diameter of a glass fiber reinforced concrete column wrap above. This concrete wrap contains eight number 4 vertical reinforcing bars and number 3 ties spaced at 8 inches on center. An exterior column finish is applied per architectural drawings.
4 S601 5/16 CONCRETE SLAB ON GRADE, SEE PLAN STEEL BASE PLATE (SEE SCHEDULE) ON 1.1/2" NON-SHRINK GROUT CONCRETE FOOTING, SEE PLAN AND SCHED STEEL COLUMN, SEE PLAN AND SCHEDULE CONCRETE BLOCKOUT EXTERIOR COLUMN FINISH, SEE ARCH WRAP ABOVE. REINFORCE WRAP WITH (8) #4 VERTICAL DIAMETER OF GFRC COLUMN COLUMN TO MATCH FINISHED CONCRETE WRAP AT STEEL BARS AND #3 TIES AT 8" O.C.
