A four-inch box jamb assembly consists of two studs matching the adjacent stud material flanked by continuous tracks on both sides. A finish is applied per architectural specifications. Welds are specified on both sides of the jamb at two inches long at the ends with specific spacing. A general note prohibits splices in the sill or sill assembly unless otherwise noted.
4" BOX JAMB SECTION__ 5B FINISH PER ARCH'L (2) STUDS MATCHING STUD MATERIAL 400T150-54 CONTINUOUS TRACK BOTH SIDES WALL OPENING BOTH SIDES OF JAMB -2" LONG AT ENDS 1/8 2-12 WALL OPENING NOTE: NO SPLICES IN SILL OR SILL ASSEMBLY PERMITTED, U.N.O.
