S-5WTCQ — Enlarged View

Structural · S-5WTCQ

Enlarged View

Units: metric
Sheet: S-MB-8.06
Discipline: Structural

Materials

Steel Timber / Wood

Elements

Connections / Plates

Connections

Bolted Connection

Text on the drawing

ENLARGED VIEW JAM NUT 75x75x32 PL TRACK ROLLER STUD TYPE FLANGED. PRO CAL #FTR-4.75 TRACK ROLLER STUD TYPE PLANE ECCENTRIC PRO CAL #PTRE-3.00 75x75x32 PL JAM NUT
