S-5V55D — Section - Pedestal 'Pd1' With Baseplate 'Bp2'

Structural · S-5V55D

Section - Pedestal 'Pd1' With Baseplate 'Bp2'

Units: imperial
Sheet: S-PK-5.33
Discipline: Structural

Materials

Concrete Masonry / CMU Reinforced Concrete Steel

Elements

Anchors / Embeds Connections / Plates Foundations / Footings Reinforcing

Connections

Base Plate / Anchorage

Text on the drawing

1100 1020 510 510 550 550 PEDESTAL TIES SEE SCHEDULE PEDESTAL REINF, SEE SCHEDULE 240 40 120 40 240 680 64 350 64 GROUT POCKET, 250DEEP MIN. 50 CLEARANCE FROM SHEAR LUG 12-36M ANCHORS DYWIDAG THREADBAR GRADE 75 ANCHORS NOT TO BE TORQUED

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
