An interior steel column supports metal decking framing from both sides with L3x3x5/16 structural steel angles welded in place. Alternate diagonal angles of the same size are installed with legs down, welded with 3/16 fillet welds at each end. Typical horizontal deck support angles utilize 1/4-inch fillet welds. Coordination with other trade contractors is required per note 4.
DECK SPAN ALTERNATE DECK SUPPORT L3X3X5/16 DIAGONAL ANGLES LEG DOWN AS ALTERNATE TO DECK SUPPORT INDICATED COORDINATE WITH OTHER TRADE CONTRACTORS SEE NOTE 4 L3X3X5/16 DECK SUPPORT SEE NOTE 4 OR SEE ALTERNATE 3/16 EACH END 1/4 TYP D DETAIL AT INTERIOR COLUMN
