This detail specifies the reinforcement and setting requirements for a floor drain within a concrete slab. Two number 4 reinforcing bars, each 3 feet long, are positioned 2 inches from the top of the slab. The drain assembly is set with a 1/4 inch slope and is installed without expansion joint material. The top of the drain is set 3/8 inch below the finish floor elevation, with a 1 inch clearance provided for the surrounding slab depression. The reinforcement layout maintains a 3 inch spacing and a 1 foot 6 inch radius around the drain center.
Text on the drawing
2#4 x 3'-0" @ 2" FROM TOP OF SLAB FLOOR DRAIN (NO EXPANSION JOINT MATERIAL) NOTE: SET TOP OF DRAIN @ 3/8" BELOW FINISH FLOOR ELEVATION 3" 1" CLR R 1'-6" SL. 1/4" DETAIL BOOK REF. SHEET: S1.04 DATE: 02/20/2023
