A backstop steel connection features a brace connected via a three-eighths-inch gusset plate to a low beam sized per plan. The brace is secured with two five-eighths-inch diameter ASTM A325 bolts. A hanger per elevation ties into the assembly near the work point. A three-sixteenths-inch fillet weld is applied on three sides to secure the gusset plate. Additional information can be referenced on sheet S1.22.
1" TYP 1" 2" 3" 2" BRACE PER ELEVATION 3/8" GUSSET PL HANGER PER ELEVATION (2) 5/8" DIA ASTM A325 BOLTS WP LOW BEAM PER PLAN 16a S1.22 FOR INFORMATION NOT SHOWN REF 3/16 3 SIDES
