A hollow structural section column is located at the corner of a concrete elevator pit wall. The assembly includes elevator pit wall reinforcing per plan with corner bars matching the size and spacing of the wall reinforcement. A typical three-inch clearance is maintained at the dirt face. Development length splice details are provided for the reinforcing bars.
1 6 1 6 COL PER PLAN CORNER BAR MATCHING SIZE & SPACING OF PIT WALL REINF Ld Ld CORNER BAR MATCHING SIZE & SPACING OF PIT WALL REINF Ld Ld ELEVATOR PIT WALL & REINF PER PLAN VIEW DIRT FACE 3"TYP AT 07 -
