A moment connection frames a steel beam into the weak axis of a column sized per plan. The connection utilizes a 1/2-inch plate welded to the column flanges and web with 1/4-inch fillet welds on three sides. Additional 3/8-inch by 4-inch required plates are positioned at the top and bottom flanges. A separate shear connection is detailed per sheet 20/S5.51.
1/4 3 1/4 3 PL 3/8 x 4 x REQ'D PL 3/8 x 4 x REQ'D SHEAR CONNECTION PER 20/S5.51 COL PER PLAN PL 1/2 1/4 PL TO COL FLANGES & WEB 1/4 3 SIDES PL 1/2
