A buckling-restrained brace frames into the intersection of a wide flange column and wide flange beam at a work point. Gusset plates and connecting elements tie the brace and beam to the column flange. Additional beam-to-column connection details are referenced on separate structural sheets.
WF BEAM SEE PLAN FOR BEAM TO COLUMN CONN INFO NOT SHOWN, SEE 7 S4-101 WF COL SEE PLAN CL COL WP CL OF BEAM BUCKLING RESTRAINED BRACE, TYP NOTE: FOR INFO NOT SHOWN & NOTED SEE & 5 S4-101 11 S4-101
