A continuous hollow structural section tube connects to a precast concrete panel via an embedded steel plate ledger and angle ledger sized per the roof framing plan. The assembly features a 1/2-inch by 10-inch by 1-foot-8-inch plate with four #7 by 5-foot long dowels bent as required, tack-welded wire mesh, and non-shrink grout filling the recess. Additional 3/4-inch side plates and a 3/4-inch end plate match the panel thickness. Reinforcing bars and ties are provided as detailed in the elevations and sections.
7 DETAIL ELEVATION A ELEVATION B C D DETAIL HSS TUBE TO CONCRETE PANEL CONNECTION SEE ROOF FRAMING PLAN FOR DETAIL ORIENTATION 11
