A wide flange column connects to a wide flange cantilever stub that extends to support an upturned wide flange beam across a six-inch clearance gap. A continuous plate with a polytetrafluoroethylene surface sliding bearing pad is placed between the structural members. A deck edge angle defines the edge of the slab. Complete joint penetration welds are specified on the top and bottom flanges of the framing connection, supplemented by five-sixteenths inch fillet welds.
WF COLUMN REF. PLAN NOTE: CONC. ON METAL DECK NOT SHOWN FOR CLARITY REF. 13/S611 FOR SEISMIC JOINT GEOMETRY USE TYPICAL BOLTED CONNECTIONS U.N.O. REF. PLAN. UPTURNED WF BEAM REF. PLAN DECK EDGE ANGLE REF. 14/S611 CONT. PLATE w/ PTFE SURFACE SLIDING BEARING PAD TYP. WF BEAM REF. PLAN TYP. WF CANTILEVER STUB REF. PLAN WF BEAM REF. PLAN (CONN. NOT SHOWN REF. PLAN) CLR. 6" 13 S602 5/16 5/16 C.J.P. TYP. TOP AND BOTT. FLANGE 5
