A buckling-restrained brace connects to a steel column and gusset plate assembly anchored to a concrete foundation. The steel column features stiffener plates on the near side and far side as required by the corebrace. A gusset plate of specified thickness connects the diagonal brace member to the column flange. A concrete block-out is formed around the column base, which rests on the concrete foundation. Base plate and anchor bolt information is coordinated per elevations.
CONC SLAB ON GRADE STL COL SEE PLAN CONCRETE BLOCK-OUT STIFF PL NS & FS AS REQ'D BY COREBRACE TYP CONC FOUNDATION WORK POINT Wc Lwc Wc Lwc COREBRACE BRB, TYP GUSSET THICKNESS, tg Wb Lwb Wb Lwb SEE ELEVATIONS FOR BASE PL & AB INFORMATION AT STRONG AXIS COLUMN Lgc Lgb 9 WELDED COREBRACE AT FOUNDATION
