An HSS post bears onto a half-inch by ten-inch by one-foot-two-inch embed plate welded with quarter-inch fillets and secured with four half-inch diameter by five-inch welded headed studs. The embed plate is cast into the top of a concrete slab sized per plan, maintaining a two-inch clear cover. Additional reinforcement consists of two number four by forty-eight-inch bars on each side and two number four by four-inch hairpins on each side spaced at twenty-four inches typical unless otherwise noted.
T/SLAB PER PLAN EMBED PL1/2x10x1'-2" W/ (4) 1/2"Ø x 5" WHS ADDL (2) #4 x 48" EA SIDE CONC SLAB PER PLAN ADDL (2) #4 x 4" HAIRPIN, EA SIDE 24" TYP, UNO 2" 3" 1/4 1/4 HSS POST PER PLAN AT CORNER OR EDGE COLUMN 1/2" MIN PER PLAN 2" CLR 9"
